DIC Series Electrodynamic Vibration Test System
The DIC Series Electrodynamic Vibration Test System is SST's next-generation digital and intelligent solution. Powered by the latest PA Series amplifiers and integrated with advanced IoT technology, it delivers high reliability, low noise, and superior energy efficiency. Specially designed for magnetically sensitive specimens, it excels in ultra-low voltage testing for high-precision sensors, gyroscopes, and perception systems, making it a preferred choice in automotive and aerospace applications.
Features
-
Advanced power modules with enhanced electromagnetic compatibility. -
4× peak power output, delivering greater capacity for shock and random vibration tests.
-
Millivolt-level system noise for ultra-low voltage and high-precision tests.
-
Real-time multi-parameter monitoring, multiple communication interfaces, and remote control capabilities.
Technical Specifications
Rated Sine Force (kN): 14.7–588
Max Shock Force (kN): 29.4–1764
Frequency Range (Hz): 2–3000
Max Acceleration (m/s²): 784–980
Max Velocity (m/s): 2–2.5
Max Displacement (mm p-p): 51–76
Max Load (kg): 200–2000
