DSS Series Long-Stroke Electrodynamic Shock Test System
The DSS Series Long-Stroke Electrodynamic Shock Test System delivers high-precision shock performance and supports a wide range of shock waveforms. It is primarily used for testing automotive components such as airbag sensors and event data recorders under shock conditions.
Features
-
Long stroke with variable shock speeds to accommodate complex test requirements. -
Customizable initial shock position with support for multiple waveform profiles.
-
Precision guidance structure ensuring accurate control during long-stroke impacts.
Technical Specifications
Max Displacement (mm p-p): 150–500
Max Velocity (m/s): 8–12
Max Acceleration (m/s²): 1470
Max Shock Force (kN): 14.7–196
Load Capacity (kg): 5
Table Size (L×W, mm, customizable): 90×275 to 800×800
